Rated power kw

160

200

240

300

400

480

Input voltage

3~ 400VAC

Input frequency

50/60 Hz

Output voltage

150~1000VDC

Output current per pistol

<300A

<300A

<300A

<300A

<300A

<300A

No of charging pistols

2

Output power per pistol

Evenly distributed within, maximum power limiting

Cable length

5 meter

Charging connector type

CCS2

Installation

Ground installed

HMI

7-inch touch screen

Charging mode

Automatic full, fixed amount, fixed time

Payment method

Payment terminal, Scan code, APP, RFID card, VIN code

Network connection

4G, Wi-Fi, Ethernet

Communication protocol

OCPP 1.6J

IP rating

IP 55

Operating temperature

-35°C ~ +55°C

Cooling method

Air cooling

Noise

≤ 50 dB

Relative humidity

5% ~ 95%

Safety and protection

Over and under voltage protection, overload protection, current leakage protection, over temperature protection, grounding protection, lightning surge protection

Other features

Automatic load balancing between charging pistols, Visualized charging progress display, Anti-corrosion galvalume housing
