V2G/V2H power bank 82~172kwh
Our V2G/V2H power bank are designed to move energy. It has a light weight and a compact size, and specifically designed and customized according to the Swedish traffic regulation to fit into a mobile usage. It is made for the Nordic weather conditions with very good corrosion protection. It is easier to move around with a fork lift or a crane, and gives strong protection against any possible collision. It is free of installation with good mobility.
Technical specification
Battery capacity kWH | 82 | 110 | 154 | 172 |
Rated power kW | 41 | 55 | 77 | 86 |
Rated voltage | 537V | |||
Input voltage AC | 3~ 400VAC | |||
Input frequency AC | 50/60 Hz | |||
Input connector AC | CEE 3~, 63A | |||
Input connector DC charging | CCS2 | |||
Output connector AC | CEE 3~ 63A, 32A, 16A; CEE 1~ 16A | |||
Output voltage DC | 150~1000VDC | |||
Cooling method | air cooling | |||
Noise | ≤ 65dB | |||
Installation | Ground installed or mobile | |||
IP rating | IP54 | |||
Operating temperature | -35°C ~ +55°C | |||
Relative humidity | 5% ~ 95% | |||
Network connectivity | 4G, Ethernet | |||
Safety and protection | Over and under voltage protection, overload protection, current leakage protection, over temperature protection, low temperature protection, grounding protection, lightning surge protection, anti-static protection, emergency stop, insulation control | |||
Other features | Built in STS function for automatic switching of power supply from grid and battery, and automatic sensing of on grid and off grid; Built in EMS for automatic self battery charging, and automatic battery discharging for AC output. | |||
PV integration | Optional, 60~80kw | |||
Weight | 1000~1500kg | |||
